Seat Belt-Retractor TENSIONER-Passenger (Standard) Connector End View (D6676A)

Harness-Family: Seat_Right

Color: BLACK

Gender: FEMALE

Part Number: 13824823

Part Description: Not Available

Connector No: D6676A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: null

Fig 1: Seat Belt-Retractor Tensioner-Passenger Connector End View (Standard)

Courtesy of CHRYSLER

Fig 2: Seat Belt-Retractor Tensioner-Passenger Component Location (Standard)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R504

0.5

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 2

N/A

R506

0.5

PASSENGER SEAT BELT RETRACTOR TENSIONER LINE 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
