Headlamp Alignment

GC0171084Courtesy of CHRYSLER GROUP, LLC
  1. Turn the headlamps ON and select the LOW beams.
  2. Use a screwdriver to rotate the headlamp vertical and horizontal adjustment (1) screws located on each front lamp unit to adjust the beam height as required.
