Shield, Splash, Front Wheelhouse: Removal

Courtesy of CHRYSLER GROUP, LLC

1. Raise and support the vehicle.
2. Remove the wheels from the side of the vehicle being serviced Refer to REMOVAL .
3. Remove the push-pins from the body side cladding.
4. Remove the 13 push-pins (2) that secure the lower front wheelhouse shield (1) to the front belly pan and the body.
5. Remove the rivet (3).
6. Remove the three screws (4).
7. Remove the front wheelhouse shield from the vehicle.
