Cladding, Body: Removal

GC0170812Courtesy of CHRYSLER GROUP, LLC
  1. Raise and support the vehicle.
  2. Remove the wheels from the side of the vehicle being serviced Refer to REMOVAL .
  3. Remove the front push pin fasteners (4).
  4. Remove the rear push pin fasteners (2).
  5. Pull sill cladding from one end and beneath until the six cross car pins are disengaged and remove the sill cladding (3).
