Shield, Splash, Rear Wheelhouse: Removal

Courtesy of CHRYSLER GROUP, LLC

1. Raise and support the vehicle.
2. Remove the wheels from the side of the vehicle being serviced. Refer to REMOVAL .
3. Remove the push-pins (6) from the body side cladding.
4. Remove the nuts (5).
5. Remove the 10 push-pins (5) that secure the rear wheelhouse shield (3) to the body.
6. Release the fasteners (2) from the studs (1).
7. Remove the rear wheelhouse shield from the vehicle.
