Heated Steering Wheel
WARNING: This page is about a different car, the 2016 Dodge Durango. However, it is still accessible from the selected car via links, so may be relevant.
The heated steering wheel system is designed to enhance the thermal comfort of the driver by heating the steering wheel.
The heated steering wheel is an option only available on vehicles that have heated seats.
The heating element is made of copper wire and located between the covering and substrate material of the steering wheel.
A vehicle with a heated steering wheel can easily be identified by the heated steering wheel switch located on the Radio Receiver Module (RRM) U-Connect touch screen.
The heated steering wheel soft switch illuminates when the heated steering wheel system is on.
The heated steering wheel system consists of the following major components
- Heated Steering Wheel Switch - Refer to SWITCH, HEATED STEERING WHEEL, DESCRIPTION .
- Heated Seat Module - Refer to MODULE, HEATED SEAT, DESCRIPTION .
- Heated Steering Wheel - Refer to OPERATION .
