Single Muffler/Resonator

WARNING: This page is about a different car, the 2016 Dodge Durango. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Single Exhaust Systems, Muffler, Resonator And Tailpipe

Courtesy of CHRYSLER GROUP, LLC

NOTE:

NOTE: Always work from the front to rear of exhaust system when aligning and tightening exhaust system components.

Position muffler/resonator assembly (2) onto the catalytic exhaust pipes.
Install support isolators.
Align muffler/resonator assembly to maintain position and proper clearance with underbody parts. All support isolators should have equal load on them.
Tighten the exhaust clamps (4) to 50 N.m (37 ft. lbs.).
Connect the ground straps.
Lower vehicle.
Start the engine and inspect for exhaust leaks. Repair exhaust leaks as necessary
