Transmitter-Intrusion Sensor (D6704A)

Harness-Family: Headliner

Color: BLACK

Gender: FEMALE

Part Number: 1488752-3

Part Description: Not Available

Connector No: D6704A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Transmitter-Intrusion Sensor Connector End View

Courtesy of CHRYSLER

Fig 2: Transmitter-Intrusion Sensor Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

A911

FUSED B(+)

N/A

D255

WT/GY

CAN IHS (+)

N/A

D254

WT/OR

CAN IHS (-)

N/A

D96

WT/LB

SIREN SIGNAL CONTROL

N/A

Z906

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
