Throttle Body (3.6L) (D6701)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 1-1718646-1

Part Description: AMP MCP 1.2 6P CONNECTOR ASSEMBLY

Connector No: D6701

Option: 3.6L

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Throttle Body Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Throttle Body Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K124

DB/GY

.50

ETC MOTOR (+)

N/A

K126

DB/LG

.50

ETC MOTOR (-)

N/A

K122

BR/DG

.50

TP 2 SIGNAL

N/A

F855

PK/YL

.50

5 VOLT SUPPLY

N/A

K22

BR/OR

.50

TP 1 SIGNAL

N/A

K922

BR/DB

.50

TP SENSOR RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
