Throttle Body (2.4L) (D6701)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 13542848

Part Description: RECEPTACLE CONNECTOR FOR MQS

Connector No: D6701

Option: 2.4L

Repair Kit Part Number: 68018956AA

Cavity Count: 6

Fig 1: Throttle Body Connector End View (2.4L)

GCWD1084373

Courtesy of CHRYSLER

Fig 2: Throttle Body Component Location (2.4L)

GCWD1188095

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K124

DB/GY

20

ETC MOTOR (+)

N/A

2

K922

BR/DB

20

TP SENSOR RETURN

N/A

3

F855

PK/YL

20

5 VOLT SUPPLY

N/A

4

K126

DB/LG

20

ETC MOTOR (-)

N/A

5

K22

BR/OR

20

TP 1 SIGNAL

N/A

6

K122

BR/DG

20

TP 2 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
