Switch-Window/Door Lock-Passenger (Express) (D2302A)

Harness-Family: Door_Front_Right

Color: GREEN

Gender: FEMALE

Part Number: 7283-9043-60

Part Description: KAIZEN 0.64 SYSTEM SUB-ASSEMBLY

Connector No: D2302A

Option: EXPRESS

Repair Kit Part Number: Not Available

Cavity Count: 10

Fig 1: Switch-Window/Door Lock-Passenger Connector End View (Express)

Courtesy of CHRYSLER

Fig 2: Switch-Window/Door Lock-Passenger Component Location (Express)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

E34

OR/TN

PASSENGER WINDOW SWITCH ILLUMINATION DRIVER

N/A

Q936

OR/LG

PASSENGER WINDOW SWITCH RETURN

N/A

G160

VT/LG

PASSENGER DOOR LOCK SWITCH MUX

N/A

Q336

OR/GY

PASSENGER WINDOW SWITCH MUX

N/A

⁽¹⁾	Pins not listed are not used for this connector
