Switch-Steering Wheel-Left (D2577A)

Harness-Family: Steering_Wheel

Color: BLACK

Gender: FEMALE

Part Number: 50-57-9404

Part Description: HSG92.54)/.100 GRID STACKABLE SINGLE ROW

Connector No: D2577A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 4

Fig 1: Switch-Steering Wheel-Left Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Steering Wheel-Left Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G106

EVIC MUX SIGNAL

N/A

STEERING WHEEL SWITCH ILLUMINATION

N/A

G907

DB/WT

EVIC MUX RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
