Switch-Seat Belt Buckle-Driver (D2281)

Harness-Family: Seat_Driver

Color: LIGHT GRAY

Gender: MALE

Part Number: 7282-6443-40

Part Description: 2P KAIZEN YESC 1.5MM MALE SUB ASSEMBLY

Connector No: D2281

Option: Standard

Repair Kit Part Number: 68065022AA

Cavity Count: 2

Fig 1: Switch-Seat Belt Buckle-Driver Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Seat Belt Buckle-Driver Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R57

LG/GY

DRIVER SEAT BELT BUCKLE SWITCH SENSE

N/A

R59

LG/TN

DRIVER SEAT BELT BUCKLE SWITCH GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
