Switch-Power Window-Right Rear (Express) (D2305A)

Harness-Family: Door_Right_Rear

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 13591369

Part Description: GT FLEX BEAM TECHNOLOGY 280 CONNECTOR

Connector No: D2305A

Option: EXPRESS

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Switch-Power Window-Right Rear Connector End View (Express)

Courtesy of CHRYSLER

Fig 2: Switch-Power Window-Right Rear Component Location (Express)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z922

GROUND

N/A

Q112

OR/BR

PASSENGER REAR WINDOW DRIVER (UP)

N/A

Q212

OR/VT

PASSENGER REAR WINDOW DRIVER (DOWN)

N/A

Q412

OR/LB

MASTER WINDOW SWITCH RIGHT REAR (UP)

N/A

Q612

OR/DB

MASTER WINDOW SWITCH RIGHT REAR (DOWN)

N/A

Q151

TN/DB

PWR WINDOW SW LOCK OUT FEED RR RT

N/A

⁽¹⁾	Pins not listed are not used for this connector
