Switch-Power Liftgate-Rear (D2365A)

Harness-Family: Liftgate

Color: BLACK

Gender: FEMALE

Part Number: 7287-1598-30

Part Description: 2P 1.5 YESC RP SLD (WHEEL SPEED) W/ CPA

Connector No: D2365A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Switch-Power Liftgate-Rear Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Power Liftgate-Rear Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

P30

TN/DG

LIFTGATE HANDLE SWITCH SENSE

N/A

P39

TN/LB

LIFTGATE EXTERIOR HANDLE SW RTN

N/A

⁽¹⁾	Pins not listed are not used for this connector
