Switch-Parking Brake C2 (D2269B)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13705266

Part Description: Not Available

Connector No: D2269B

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 1

Fig 1: Switch-Parking Brake C2 Connector End View

GCWD1092762

Courtesy of CHRYSLER

Fig 2: Switch-Parking Brake C2 Component Location

GCWD1188305

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

B25

DG/WT

20

PARK BRAKE SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
