Switch-Headlamp Leveling (D2243A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 638393-5

Part Description: CONNNECTOR - PLUG ASSEMBLY

Connector No: D2243A

Option: Standard

Repair Kit Part Number: 68057283AA

Cavity Count: 10

Fig 1: Switch-Headlamp Leveling Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Headlamp Leveling Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

L900

WT/YL

HEADLAMP SWITCH MUX RETURN

N/A

OR/BR

PANEL LAMPS DRIVER

N/A

Z926

GROUND

N/A

E12

OR/GY

PANEL LAMPS DRIVER

N/A

L135

HEADLAMP LEVEL CONTROL SIGNAL

N/A

L13

WT/TN

HEADLAMP LEVEL SENSOR SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
