Switch-Headlamp (D2242A)

Harness-Family: IP

Color: BLACK

Gender: FEMALE

Part Number: 1488752-3

Part Description: Not Available

Connector No: D2242A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 6

Fig 1: Switch-Headlamp Connector End View

GCWD1006451

Courtesy of CHRYSLER

Fig 2: Switch-Headlamp Component Location

GCWD1188389

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

3

L307

WT/BR

22

HEADLAMP SWITCH MUX

N/A

4

Z926

BK

22

GROUND

N/A

5

E12

OR/GY

22

PANEL LAMPS DRIVER

N/A

6

L900

WT/YL

22

HEADLAMP SWITCH MUX RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
