Switch-EVAP System Monitor (D6623A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13593246

Part Description: 2P ACTIVE TERMINAL SYSTEM 2.8 CONN ASM

Connector No: D6623A

Option: Standard

Repair Kit Part Number: 68272950AA

Cavity Count: 2

Fig 1: Switch-EVAP System Monitor Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-EVAP System Monitor Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z911

BK/LB

GROUND

N/A

K108

EVAP PURGE SOLENOID SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
