Switch-Clutch Interlock/UPSTOP (D2312A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 56038153

Part Description: 3 WAY APEX CONNECTOR

Connector No: D2312A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Switch-Clutch Interlock/upstop Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Clutch Interlock/upstop Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T26

DG/OR

CLUTCH UPSTOP SIGNAL

N/A

Z901

GROUND

N/A

T141

YL/OR

CLUTCH INTERLOCK SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
