Switch-Backup Lamp (D2209A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 282080-1

Part Description: AMP SUPER SEAL 1.5 SERIES CONNECTOR

Connector No: D2209A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Switch-Backup Lamp Connector End View

Courtesy of CHRYSLER

Fig 2: Switch-Backup Lamp Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z902

GROUND

N/A

T22

YL/VT

BACKUP LAMP SWITCH SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
