Starter-Eyelet-A (2.4L/3.6L) (D6637A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 520961-1

Part Description: INSL

Connector No: D6637A

Option: 2.4L/3.6L

Repair Kit Part Number: 05019927AA

Cavity Count: 1

Fig 1: Starter-Eyelet-A Connector End View (2.4L/3.6L)

Courtesy of CHRYSLER

Fig 2: Starter-Eyelet-A Component Location (2.4L/3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T750

YL/GY

STARTER RELAY OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
