Speaker-Tweeter-Right Front (D5922A)

Harness-Family: IP

Color: NATURAL

Gender: FEMALE

Part Number: 13578360

Part Description: 070 SERIES UNSEALED Female CONNECTOR

Connector No: D5922A

Option: Standard

Repair Kit Part Number: 68272949AA

Cavity Count: 2

Fig 1: Speaker-Tweeter-Right Front Connector End View

Courtesy of CHRYSLER

Fig 2: Speaker-Tweeter-Right Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X202

DG/VT

RIGHT FRONT SPEAKER (+)

N/A

X292

DG/YL

RIGHT FRONT SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
