Speaker-Tweeter-Left Front (D5921A)

Harness-Family: IP

Color: NATURAL

Gender: FEMALE

Part Number: 13578360

Part Description: 070 SERIES UNSEALED Female CONNECTOR

Connector No: D5921A

Option: Standard

Repair Kit Part Number: 68272949AA

Cavity Count: 2

Fig 1: Speaker-Tweeter-Left Front Connector End View

Courtesy of CHRYSLER

Fig 2: Speaker-Tweeter-Left Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X201

GY/VT

LEFT FRONT SPEAKER (+)

N/A

X291

GY/YL

LEFT FRONT SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
