Speaker-Instrument Panel-Right (D5916A)

Harness-Family: IP

Color: NATURAL

Gender: FEMALE

Part Number: 13578360

Part Description: 070 SERIES UNSEALED Female CONNECTOR

Connector No: D5916A

Option: Standard

Repair Kit Part Number: 68272949AA

Cavity Count: 2

Fig 1: Speaker-Instrument Panel-Right Connector End View

Courtesy of CHRYSLER

Fig 2: Speaker-Instrument Panel-Right Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

X208

GY/DG

AMPLIFIED RIGHT I/P SPEAKER (+)

N/A

X298

GY/LG

AMPLIFIED RIGHT I/P SPEAKER (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
