Solenoid-Oil Pump (3.6L) (D2555)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 872-857-501

Part Description: MLK CONNECTOR

Connector No: D2555

Option: 3.6L

Repair Kit Part Number: 68137868AA

Cavity Count: 2

Fig 1: Solenoid-Oil Pump Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Solenoid-Oil Pump Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G62

VT/YL

.50

OIL PRESSURE SOL CONTROL

N/A

Z901

.75

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
