Solenoid-Headrest-Right Front (D2589)

Harness-Family: Airbag_Side_Right

Color: YELLOW

Gender: MALE

Part Number: 174057-1

Part Description: Not Available

Connector No: D2589

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Solenoid-Headrest-Right Front Connector End View

Courtesy of CHRYSLER

Fig 2: Solenoid-Headrest-Right Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z922

GROUND

N/A

R677

PK/YL

PASSENGER ACTIVE HEAD RESTRAINT SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
