Solenoid-Electronically Controlled Clutch (D62A)

Harness-Family: Fuel_Tank

Color: GRAY

Gender: FEMALE

Part Number: 12162017

Part Description: 150 SERIES SEALED 2WAY

Connector No: D62A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Solenoid-Electronically Controlled Clutch Connector End View

Courtesy of CHRYSLER

Fig 2: Solenoid-Electronically Controlled Clutch Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T315

YL/BR

SHIFT MOTOR CONTROL A

N/A

T316

YL/GY

SHIFT MOTOR CONTROL B

N/A

⁽¹⁾	Pins not listed are not used for this connector
