Solenoid-EVAP/Purge (D21A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 13578470

Part Description: CONNECTOR ASSEMBLY

Connector No: D21A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 2

Fig 1: Solenoid-EVAP/Purge Connector End View

GCWD1080636

Courtesy of CHRYSLER

Fig 2: Solenoid-EVAP/Purge Component Location

GCWD1187924

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K52

DB/WT

20

EVAP PURGE CONTROL

N/A

2

K70

DB/BR

20

EVAP PURGE SOL SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
