Sensor-Wheel Speed-Abs-Right Rear (D1575A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13627749

Part Description: ASM CONN 2 F GT FBT 150 BLK SLD

Connector No: D1575A

Option: Standard

Repair Kit Part Number: 68052575AA

Cavity Count: 2

Fig 1: Sensor-Wheel Speed-ABS-Right Rear Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Wheel Speed-ABS-Right Rear Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

DG/LB

RIGHT REAR WHEEL SPEED SENSOR (+)

N/A

DG/OR

RIGHT REAR WHEEL SPEED SENSOR (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
