Sensor-Water In Fuel (D1571A)

Harness-Family: HDLP_Dash

Color: GREEN

Gender: FEMALE

Part Number: 184006-1

Part Description: INSULATOR

Connector No: D1571A

Option: Standard

Repair Kit Part Number: 05014005AA

Cavity Count: 2

Fig 1: Sensor-Water In Fuel Connector End View

GCWD1006505

Courtesy of CHRYSLER

Fig 2: Sensor-Water In Fuel Component Location

GCWD1187973

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K923

BR/WT

18

WATER IN FUEL SENSOR GROUND

N/A

2

G123

VT/LG

18

WIF SENSOR 1 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
