Sensor-Washer Fluid Level-Front (D2299A)

Harness-Family: Front_End_Lighting

Color: BLACK

Gender: FEMALE

Part Number: 13627751

Part Description: ASM CONN 2 F GT FBT 150 BLK SLD

Connector No: D2299A

Option: Standard

Repair Kit Part Number: 68045333AA

Cavity Count: 2

Fig 1: Sensor-Washer Fluid Level-Front Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Washer Fluid Level-Front Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

W11

BR/TN

LOW WASH SW RTN 1

N/A

BR/TN

WASHER FLUID LEVEL SWITCH SENSE

N/A

⁽¹⁾	Pins not listed are not used for this connector
