Sensor-VGT (D1635)

Harness-Family: Engine_Diesel

Color: BLACK

Gender: FEMALE

Part Number: 1-06046-97

Part Description: Not Available

Connector No: D1635

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Sensor-VGT Connector End View

GCWD1092359

Courtesy of CHRYSLER

Fig 2: Sensor-VGT Component Location

GCWD1188007

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K632

BR/LG

20

TURBO VALVE POS SIG

N/A

2

K633

GY/YL

20

TURBO VALVE POS SIG 2

N/A

3

K634

WT/DB

20

TURBO VALVE POS SIG 3

N/A

⁽¹⁾	Pins not listed are not used for this connector
