Sensor-Transfer Speed (Diesel/2.4L) (D1662A)

Harness-Family: Transmission

Color: BLACK

Gender: FEMALE

Part Number: 184000-1

Part Description: SEALED SENSOR CONNECTOR

Connector No: D1662A

Option: DIESEL/2.4L

Repair Kit Part Number: 05014002AA

Cavity Count: 2

Fig 1: Sensor-Transfer Speed Connector End View (Diesel/2.4L)

Courtesy of CHRYSLER

Fig 2: Sensor-Transfer Speed Component Location (Diesel/2.4L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T85

DG/LG

TRANSFER SPEED SIGNAL

N/A

T13

DG/VT

SPEED SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
