Sensor-Side Impact-Right 1B (D2606A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13623700

Part Description: Not Available

Connector No: D2606A

Option: Standard

Repair Kit Part Number: 68057306AA

Cavity Count: 2

Fig 1: Sensor-Side Impact-Right 1b Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact-Right 1b Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R161

RIGHT SIDE IMPACT SENSOR 1 GROUND

N/A

R141

RIGHT SIDE IMPACT SENSOR 2 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
