Sensor-Side Impact-Left 3 (D1530A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 13623700

Part Description: Not Available

Connector No: D1530A

Option: Standard

Repair Kit Part Number: 68057306AA

Cavity Count: 2

Fig 1: Sensor-Side Impact-Left 3 Connector End View

Courtesy of CHRYSLER

Fig 2: Sensor-Side Impact-Left 3 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

R23

LB/YL

LEFT SIDE IMPACT SENSOR 3 GROUND

N/A

R21

LB/DB

LEFT SIDE IMPACT SENSOR 3 SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
