Sensor-Output Speed (62TE/3.6L) (D1545A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 184000-1

Part Description: SEALED SENSOR CONNECTOR

Connector No: D1545A

Option: 62TE/3.6L

Repair Kit Part Number: 05014002AA

Cavity Count: 2

Fig 1: Sensor-Output Speed Connector End View (62TE/3.6L)

Courtesy of CHRYSLER

Fig 2: Sensor-Output Speed Component Location (62TE/3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

T14

DG/BR

.75

OUTPUT SPEED SIGNAL

N/A

T13

DG/VT

.80

SPEED SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
