Sensor-Manifold Absolute Pressure (3.6L) (D1537A)

Harness-Family: Engine

Color: BLACK

Gender: FEMALE

Part Number: 1488991-6

Part Description: Not Available

Connector No: D1537A

Option: 3.6L

Repair Kit Part Number: 68137870AA

Cavity Count: 3

Fig 1: Sensor-Manifold Absolute Pressure Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Sensor-Manifold Absolute Pressure Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

VT/BR

.50

MAP SIGNAL

N/A

K900

DB/DG

.75

SENSOR GROUND

N/A

F856

YL/PK

.50

5 VOLT SUPPLY

N/A

⁽¹⁾	Pins not listed are not used for this connector
