Sensor-Knock 2 (D1535)

Harness-Family: Sensor_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 963040-3

Part Description: 2P JPT CONNECTOR ASSEMBLY

Connector No: D1535

Option: Standard

Repair Kit Part Number: 68032285AA

Cavity Count: 2

Fig 1: Sensor-Knock 2 Connector End View

GCWD1006327

Courtesy of CHRYSLER

Fig 2: Sensor-Knock 2 Component Location

GCWD1188028

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K242

BR/WT

20

KS 2 SIGNAL

N/A

2

K924

WT/BR

20

KS 2 RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
