Sensor-Knock 1 (3.6L) (D1534)

Harness-Family: Sensor_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 963040-3

Part Description: 2P JPT CONNECTOR ASSEMBLY

Connector No: D1534

Option: 3.6L

Repair Kit Part Number: 68032285AA

Cavity Count: 2

Fig 1: Sensor-Knock 1 Connector End View (3.6L)

GCWD1006327

Courtesy of CHRYSLER

Fig 2: Sensor-Knock 1 Component Location (3.6L)

GCWD1188025

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K42

DB/YL

18

KS 1 SIGNAL

N/A

2

K942

BR/LG

18

KS 1 RETURN

N/A

⁽¹⁾	Pins not listed are not used for this connector
