Sensor-Fuel Temperature (D1519A)

Harness-Family: HDLP_Dash

Color: BLACK

Gender: FEMALE

Part Number: 1928403874

Part Description: INSULATOR

Connector No: D1519A

Option: Standard

Repair Kit Part Number: 68065018AA

Cavity Count: 2

Fig 1: Sensor-Fuel Temperature Connector End View

GCWD1006296

Courtesy of CHRYSLER

Fig 2: Sensor-Fuel Temperature Component Location

GCWD1188424

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

K159

BR/YL

18

FUEL TEMP SNSR RTN

N/A

2

K156

BR/WT

18

FUEL TEMP SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
