Sensor-Engine Oil Temperature (3.6L) (D1544A)

Harness-Family: Sensor_Jumper

Color: BLACK

Gender: FEMALE

Part Number: 7287-0027-30

Part Description: 2P 1.5MM YESC (5.0MM PITCH) SUB-ASSEMBLY

Connector No: D1544A

Option: 3.6L

Repair Kit Part Number: 68064995AA

Cavity Count: 2

Fig 1: Sensor-Engine Oil Temperature Connector End View (3.6L)

Courtesy of CHRYSLER

Fig 2: Sensor-Engine Oil Temperature Component Location (3.6L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G224

VT/YL

EOT SIGNAL

N/A

K900

DB/DG

SENSOR GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
