Sensor-Engine Oil Temperature (2.4L) (D1544A)

Harness-Family: Engine

Color: DARK GRAY

Gender: FEMALE

Part Number: 13592516

Part Description: GT 150 CONNECTOR ASSEMBLY

Connector No: D1544A

Option: 2.4L

Repair Kit Part Number: 68057314AA

Cavity Count: 2

Fig 1: Sensor-Engine Oil Temperature Connector End View (2.4L)

Courtesy of CHRYSLER

Fig 2: Sensor-Engine Oil Temperature Component Location (2.4L)

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

K914

BR/WT

SENSOR GROUND

N/A

G24

VT/BR

EOT SIGNAL

N/A

⁽¹⁾	Pins not listed are not used for this connector
