Module-Steering Control C1 (D3816A)

Harness-Family: IP

Color: NATURAL

Gender: FEMALE

Part Number: 638100-1

Part Description: INSULATOR

Connector No: D3816A

Option: Standard

Repair Kit Part Number: 68080563AA

Cavity Count: 6

Fig 1: Module-Steering Control C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Steering Control C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z926

GROUND

N/A

D507

OR/WT

LIN BUS

N/A

A929

FUSED B(+)

N/A

V72

OR/VT

S/C SIGNAL 2

N/A

V937

VT/BR

S/C SWITCH GROUND

N/A

V71

VT/OR

S/C SIGNAL 1

N/A

⁽¹⁾	Pins not listed are not used for this connector
