Module-Park Assist C1 (D3867A)

Harness-Family: Body

Color: BLACK

Gender: FEMALE

Part Number: 7283-9052-30

Part Description: YESC KAIZEN SUB- ASSEMBLY

Connector No: D3867A

Option: Standard

Repair Kit Part Number: 68080557AA

Cavity Count: 12

Fig 1: Module-Park Assist C1 Connector End View

GCWD1016838

Courtesy of CHRYSLER

Fig 2: Module-Park Assist C1 Component Location

GCWD1188188

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

F923

PK/YL

22

RUN RELAY CONTROL

N/A

6

D77

VT

22

CAN C (+)

N/A

11

Z911

BK/LB

22

GROUND

N/A

12

D78

YL

22

CAN C (-)

N/A

⁽¹⁾	Pins not listed are not used for this connector
