Module-Heated Seats C1 (D3846A)

Harness-Family: Seat_Driver

Color: BLACK

Gender: FEMALE

Part Number: 1-929172-1

Part Description: MQS AND MCP SOCKET HOUSING AND COVER

Connector No: D3846A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 5

Fig 1: Module-Heated Seats C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Heated Seats C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

D265

WT/GY

CAN IHS (+)

N/A

D264

WT/OR

CAN IHS (-)

N/A

Z921

GROUND

N/A

F921

PK/YL

FUSED IGNITION RUN CONTROL OUTPUT

N/A

⁽¹⁾	Pins not listed are not used for this connector
