Module-Body Control C2/B (D3806B)

Harness-Family: HDLP_Dash

Color: LIGHT GRAY

Gender: FEMALE

Part Number: 7283-6469-40

Part Description: KAIZEN CONNECTOR SUB ASSEMBLY

Connector No: D3806B

Option: Standard

Repair Kit Part Number: 68052581AA

Cavity Count: 4

Fig 1: Module-Body Control C2/b Connector End View

Courtesy of CHRYSLER

Fig 2: Module-Body Control C2/b Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

Z904

GROUND

N/A

A904

FUSED B(+)

N/A

⁽¹⁾	Pins not listed are not used for this connector
