Lighter-Cigar (D6601A)

Harness-Family: IP

Color: CREAM

Gender: FEMALE

Part Number: 12176445

Part Description: METRI-PACK 280 UNSEALED Female CONNECTOR

Connector No: D6601A

Option: Standard

Repair Kit Part Number: Not Available

Cavity Count: 3

Fig 1: Lighter-Cigar Connector End View

Courtesy of CHRYSLER

Fig 2: Lighter-Cigar Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

F984

PK/YL

IGNITION SWITCH OUTPUT

N/A

Z906

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
