Latch-Door-Liftgate C1 (D6614A)

Harness-Family: Liftgate

Color: NATURAL

Gender: FEMALE

Part Number: 13578360

Part Description: 070 SERIES UNSEALED Female CONNECTOR

Connector No: D6614A

Option: Standard

Repair Kit Part Number: 68272949AA

Cavity Count: 2

Fig 1: Latch-Door-Liftgate C1 Connector End View

Courtesy of CHRYSLER

Fig 2: Latch-Door-Liftgate C1 Component Location

Courtesy of CHRYSLER

Circuit

Wire Color

Gauge/Size

Function

Option

G78

VT/OR

DECKLID/LIFTGATE AJAR SWITCH SENSE

N/A

Z911

BK/LB

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
