Lamp-Vanity-Right (D6652A)

Harness-Family: Headliner

Color: BLACK

Gender: FEMALE

Part Number: 12047662

Part Description: INSULATOR

Connector No: D6652A

Option: Standard

Repair Kit Part Number: 68272954AA

Cavity Count: 2

Fig 1: Lamp-Vanity-Right Connector End View

GCWD1006462

Courtesy of CHRYSLER

Fig 2: Lamp-Vanity-Right Component Location

GCWD1188151

Courtesy of CHRYSLER

Pin

Circuit

Wire Color

Gauge/Size

Function

Option

1

M27

YL/LB

20

READING LAMPS DRIVER

N/A

2

Z906

BK

20

GROUND

N/A

⁽¹⁾	Pins not listed are not used for this connector
